1. Applications: electric valves/inverter home appliances/ultra-thin fans/air conditioners/microwave ovens/jewelry and toys/inverter air conditioners/central air conditioning
2. Voltage: AC 220-240V / AC 24V
3. Frequency: 50/60Hz
4. Output power: 3~10W
5. Spindle speed: 1~60 RPM
6. Braking torque: 1 RPM: 320 Kgf-cm
7. Spindle rotation direction: the direction varies depending on the speed, with both forward and reverse rotation options.
8. Insulation withstand voltage: AC 1500V - 1 Min
9. Insulation class: A, B Class
10. Standard wiring: 1007 X AWG#22 X 200 mm
11. Low noise, spring return, long operating life
12. Gear set is a combination of copper and steel gears
13. Long-term locking capability, motor is not easily burned out
Specification:
|
Package Weight
|
| One Package Weight |
0.50kgs / 1.11lb
|
| One Package Size |
16cm * 9cm * 11cm / 6.3inch * 3.54inch * 4.33inch
|
| Carton Weight |
19.10kgs / 42.11lb
|
| Carton Size |
50cm * 38cm * 35cm / 19.69inch * 14.96inch * 13.78inch
|
| Loading Container |
20GP: 401 cartons * 36 pcs = 14436 pcs
40HQ: 930 cartons * 36 pcs = 33480 pcs
|
|
