Product features:
1. Adopts FT232BL chip with external EEPRON (93C46)
2. Support Windows 10
3. Support 3 power supply modes: 5V external power supply, 3.3V external power supply, external power supply (requires 3.3V-5V)
4. With 3 LEDs: TXD LED, RXD LED, POWER LED
5. GND, RXD, TXD, 3V3, 5V: using a curved pin pin out
6. The rest of the function PIN: reserved pads CTS, RTS
Instructions for use: (to access the MCU as an example)
1. GND: connected to GND
2. RXD: connect to MCU.TX (Signal flow: MCU.TX - FT232 - PC.RX)
3. TXD: connect to MCU.RX (signal flow: PC.TX - FT232 - MCU.RX)
4. 3V3/5V: output 3.3V or 5V (the module is powered by USB, the jumper cap must be jumped to 3.3V or 5V)
5. RTS: connect to MCU.CTS (signal flow: PC.RTS - FT232 - MCU.CTS)
6. CTS: connect to MCU.RTS (Signal flow: MCU.RTS - FT232 - PC.CTS)
Specification:
|
Package Weight
|
| One Package Weight |
0.07kgs / 0.14lb
|
| One Package Size |
10cm * 5cm * 2cm / 3.94inch * 1.97inch * 0.79inch
|
| Carton Weight |
21.40kgs / 47.18lb
|
| Carton Size |
52cm * 32cm * 32cm / 20.47inch * 12.6inch * 12.6inch
|
| Loading Container |
20GP: 500 cartons * 450 pcs = 225000 pcs
40HQ: 1162 cartons * 450 pcs = 522900 pcs
|
|
