I. Electrical Performance:
1. Rated Current: 5.0A
2. Contact Resistance: 40 milliohms maximum
3. Withstanding Voltage: 100V AC / 1mA MAX
4. Insulation Resistance: 150V DC / 100 megohms minimum
II. Mechanical Performance:
1. Insertion Force: 5~20N
2. Withdrawal Force: 8~20N
3. Service Life: 10,000 cycles, withdrawal force 5N MIN
Specification:
|
Package Weight
|
| One Package Weight |
0.07kgs / 0.16lb
|
| One Package Size |
14cm * 10cm * 5cm / 5.51inch * 3.94inch * 1.97inch
|
| Carton Weight |
4.50kgs / 9.92lb
|
| Carton Size |
30cm * 42cm * 32cm / 11.81inch * 16.54inch * 12.6inch
|
| Loading Container |
20GP: 661 cartons * 48 pcs = 31728 pcs
40HQ: 1535 cartons * 48 pcs = 73680 pcs
|
|
