1. Material: copper + reinforced flame-retardant nylon
2. Current: 300A (continuous); 400A (intermittent)
3. Operating voltage: 6-32V
4. Function: the dual-battery selector switch allows switching an isolated battery pack to all loads or combining the battery pack to all loads. The on-the-fly design allows switching without interrupting power.
5. Current: the 300A continuous rated current is safe for installation on gasoline-powered boats; the 400A intermittent rated current is the amount of current that can be applied within a specified shortest time period.
6. Suitable for 2 batteries: the disconnect switch allows selection between starting and charging batteries, or both in parallel.
7. General applications: the dual-battery disconnect switch is universal and widely used in marine, boat, RV, large truck, and modified vehicle applications.
8. Net weight: 443g
Specification:
|
Package Weight
|
| One Package Weight |
0.49kgs / 1.09lb
|
| One Package Size |
15cm * 15cm * 10cm / 5.91inch * 5.91inch * 3.94inch
|
| Carton Weight |
10.00kgs / 22.05lb
|
| Carton Size |
47cm * 32cm * 32cm / 18.5inch * 12.6inch * 12.6inch
|
| Loading Container |
20GP: 554 cartons * 18 pcs = 9972 pcs
40HQ: 1286 cartons * 18 pcs = 23148 pcs
|
|
