1. Rated Current: 2-500A
2. Rated Voltage: 32V DC
3. Material: PA (Polyamide) + Nickel-Plated Copper Alloy
4. Temperature Range: Normal operation from a low temperature of -20 degrees Celsius to a high temperature of +180 degrees Celsius.
5. Compatible Fuse Holders: 4x ANS Mini Bolt-Down Fuse Holders + 2x ANM Mega Bolt-Down Fuse Holders
6. Application Scope: Suitable for Electric Vehicles (EVs), Car Audio Systems, Main Fuse Box Assemblies, Sightseeing/Firefighting/New Energy Vehicles, Forklifts, Air Conditioning Systems, Buses, as well as High-Power Meters, High-Consumption Instruments, Generators, etc.
Specification:
|
Package Weight
|
| One Package Weight |
0.32kgs / 0.71lb
|
| One Package Size |
16cm * 14cm * 6cm / 6.3inch * 5.51inch * 2.36inch
|
| Carton Weight |
10.70kgs / 23.59lb
|
| Carton Size |
34cm * 44cm * 32cm / 13.39inch * 17.32inch * 12.6inch
|
| Loading Container |
20GP: 557 cartons * 30 pcs = 16710 pcs
40HQ: 1293 cartons * 30 pcs = 38790 pcs
|
|
