1. Printing method: thermal line printing
2. Printing speed: 50-80mm/s
3. Barcode type: UPC-A/UPC-E/EAN8/EAN13/CODE39/ITF/CODEBAR/CODE128/CODE93
4. Interface: Bluetooth, Type-C
5. Resolution: 203dpi
6. Effective printing width: 48mm
7. Paper width: 58mm
8. Paper thickness: 60-80μm
9. Recommended paper: FD210, PD150R, PD160R
10. Graphics: Supports bitmap printing of different densities and user-defined bitmap printing (up to 40K per bitmap, up to 64K in total)
11. Charger: 5V/1A adapter, 5V/500mA computer USB connector
12. Battery capacity: 2000mAh/3.7V
13. Print life: 50km (print density does not exceed 12.5%)/100 million pulses
14. Storage environment: -20 degrees Celsius to 70 degrees Celsius
15. Working temperature: -10 degrees Celsius to 50 degrees Celsius
16. Working humidity: 20%-85%
17. Driver: Windows XP//Win7/Win8/Win10
18. Emulation: ESC/POS compatible command set
Specification:
|
Package Weight
|
| One Package Weight |
0.23kgs / 0.52lb
|
| One Package Size |
15cm * 10cm * 8cm / 5.91inch * 3.94inch * 3.15inch
|
| Carton Weight |
18.20kgs / 40.12lb
|
| Carton Size |
52cm * 47cm * 42cm / 20.47inch * 18.5inch * 16.54inch
|
| Loading Container |
20GP: 259 cartons * 75 pcs = 19425 pcs
40HQ: 603 cartons * 75 pcs = 45225 pcs
|
|
