1. COMFAST Plrey R702 is a high-performance outdoor 4G wireless AP router, specifically designed for stable network connectivity in complex environments. It supports global LTE bands, WiFi 6 technology, and IP66 protection rating, making it suitable for remote work, video surveillance, RV camping, and outdoor broadband backup scenarios.
2. Tri-SIM Compatibility: Supports Standard SIM, Micro SIM, and Nano SIM cards, compatible with mainstream global carriers.
3. Global Band Coverage: Supports LTE-FDD B1/B3/B7/B8/B20 and LTE-TDD B38/B40/B41, as well as WCDMA B1/B8, covering most regions in Asia, Europe, and Africa.
4. 4G CAT4 High-Speed Transmission: Up to 150Mbps downlink and 50Mbps uplink speeds, meeting demands for HD video streaming, smart home monitoring, and network backup.
5. WiFi 6 Technology: Enhances network efficiency and reduces congestion during multi-device connections. Supports up to 16 simultaneous device connections (phones, laptops, cameras, etc.) and is backward compatible with WiFi 5/WiFi 4.
6. IP66 Protection Rating: Features dustproof and waterproof design, ensuring stable operation in extreme temperatures and during rain or snow.
7. Upgradable Antenna System: Comes standard with 2×5dBi omnidirectional antennas. Supports optional high-gain antennas to enhance LTE reception in weak signal areas.
8. Flexible Installation: Can be mounted on outdoor walls to ensure unobstructed 4G signal; Supports converting 4G to wired connection, providing stable internet for indoor routers.
Specifications:
1. Chipset: Quectel CL920 JR3 V2.0-EU (Asia/Europe/Africa version)
2. Speed:
-- WiFi: 300Mbps
-- LTE Cat4: 150Mbps (DL MAX) / 50Mbps (UL MAX)
3. Physical Interfaces:
-- 1x Nano SIM Card Slot
-- 1x 10/100Mbps RJ45 LAN Ethernet Port
-- 1x Reset Button
-- 1x DC Power Port
4. Indicators: POWER / LAN / WiFi / 4G / Signal Strength Lights
5. Power Supply: DC 12V/1A Power Supply
Package Contents: 4G Router / Network Cable / Cable Ties / Mounting Screws / Power Adapter / User Manual
Specification:
|
Package Weight
|
| One Package Weight |
0.53kgs / 1.18lb
|
| One Package Size |
23cm * 21cm * 6cm / 9.06inch * 8.27inch * 2.36inch
|
| Carton Weight |
11.70kgs / 25.79lb
|
| Carton Size |
54cm * 42cm * 26cm / 21.26inch * 16.54inch * 10.24inch
|
| Loading Container |
20GP: 452 cartons * 20 pcs = 9040 pcs
40HQ: 1049 cartons * 20 pcs = 20980 pcs
|
|
