1. The device sends PWM pulse signals to the fuel injector in different preset modes, so as to observe the working state of the fuel injector and judge the quality of the fuel injector
2. Supports 5V/12V two voltage fuel injectors, and tests the fuel injectors through preset frequency and pulse value
3. This instrument can help you diagnose fuel injector problems. You can test the fuel injectors one by one to help confirm the jamming, leakage or combustion completion
4. Powered by a DC jack power adapter, the continuous working mode can identify the quality of the fuel injector when the engine is turned off. This instrument can be used with any fuel pressure tester
5. Supports 5 working modes (mode 1~mode 4 are preset modes, mode 5 is a custom mode [custom pulse width, frequency, test times]
6. Supports 5V/12V two different voltage fuel injector tests
7. High-definition screen display, display frequency, pulse width, test times and other parameter information, the test results are clearly visible
8. Buzzer prompts, test process prompts
9. Input voltage supports VDC 8V~18V
10. Output voltage supports VDC 0V~80V
11. Current supports 0A~8A
12. Short circuit protection (short circuit during the test, millisecond level protection equipment)
13. Supports 12V 2A power adapter and external car battery power supply
14. One to two, can test 2 injectors at the same time, easy to compare
15. High-definition backlit screen, using broken code screen display, clearer reading, day and night dual use
16. Size: 160x62x22mm
Specification:
|
Package Weight
|
| One Package Weight |
0.35kgs / 0.78lb
|
| One Package Size |
15cm * 19cm * 7cm / 5.91inch * 7.48inch * 2.76inch
|
| Carton Weight |
8.80kgs / 19.40lb
|
| Carton Size |
39cm * 30cm * 34cm / 15.35inch * 11.81inch * 13.39inch
|
| Loading Container |
20GP: 670 cartons * 22 pcs = 14740 pcs
40HQ: 1556 cartons * 22 pcs = 34232 pcs
|
|
