1. Weight: 90g
2. Wire length: 15cm
3. Output voltage: 8v
Installation precautions:
1. The rectifier should be installed in a location with good ventilation and good heat dissipation. High temperature will be generated when the rectifier is working, and poor heat dissipation will damage the rectifier
2. The installation steps of the rectifier are to connect the AC input line, the positive and negative output are not connected, start the locomotive, measure the positive and negative output voltage, and when the voltage range is reasonable, plug in the positive and negative wires, and then test the positive and negative of the battery or rectifier If the voltage range is unreasonable, stop using it and give feedback. The entire installation process should be recorded and saved.
3. Note that the rectifier should be closely attached to the frame when installing it, which is good for heat conduction. You can also add thermally conductive glue between the rectifier and the frame
4. Do not press other wires between the rectifier and the frame
5. There should be a fuse protection device between the positive outlet of the rectifier and the battery to prevent the rectifier from being damaged and the voltage is too high and other electrical components are burned out
Applicable models:
For SKU 73297
For Golf Cart Rectifiers 1025159-01, 102515901, 1028033-01, 102803301
For Club Car Voltage Regulator PRECE NT 2004 UP # 102803301
For Genuine OEM Club Car PRECE NT Golf Cart Voltage Regulator # 1025159-01
For NEW Vootage Regulator Club Car PRECE NT 4-CYCLE
For GAS Golf Cart 12VOLT 1025159-01
Specification:
|
Package Weight
|
| One Package Weight |
0.10kgs / 0.22lb
|
| One Package Size |
12cm * 10cm * 5cm / 4.72inch * 3.94inch * 1.97inch
|
| Carton Weight |
30.00kgs / 66.14lb
|
| Carton Size |
50cm * 50cm * 60cm / 19.69inch * 19.69inch * 23.62inch
|
| Loading Container |
20GP: 177 cartons * 242 pcs = 42834 pcs
40HQ: 412 cartons * 242 pcs = 99704 pcs
|
|
