Specification:
1. Magnification: Continuous zoom 6.5X to 65X
2. Head: 45-degree inclined 360-degree swiveling trinocular
3. Eyepiece: WF10X/22MM
4. Objective: 0.65-6.5X
5. Camera connector: 0.5X
7. Monitor and eyepiece: Synchronous zoom
8. Accessories: 144 adjustable led lights & dust proof Lens
Support Parameters:
1. Column aperture: 32mm
2. Lens aperture: 76mm
3. Center distance: 155mm
4. Lifting range: 50mm
Wide-angle Eyepieces 10X/22:
1. Magnification: 10X
2. Wide field of view 22mm
3. Matching size: 30mm
4. Applicable models: Stereoscopic, fixed, and continuous magnification microscopes
144 LED Ring Light:
1. Input: AC 100~240V 50/60Hz
2. Output: DC 12V, Max 700mA
3. Light color: White
4. Number of lights: 144 LEDs
5. Inside diameter: 60mm
Package includes:
1. Microscope x 1
2. Aluminum Alloy Plate x 1
3. 144 LED Light x 1
4. Dustproof Len x 1
5. CTV Lens x 1
Specification:
|
Package Weight
|
| One Package Weight |
5.50kgs / 12.13lb
|
| One Package Size |
42cm * 33cm * 26cm / 16.54inch * 12.99inch * 10.24inch
|
| Carton Weight |
12.00kgs / 26.46lb
|
| Carton Size |
44cm * 35cm * 53cm / 17.32inch * 13.78inch * 20.87inch
|
| Loading Container |
20GP: 326 cartons * 2 pcs = 652 pcs
40HQ: 758 cartons * 2 pcs = 1516 pcs
|
|
