1. Type: Test Block
2. Working frequency: High frequency
3. Application: Integrated Circuit IC
4. Contact impedance: Less than 25 milliohms
5. Production process: Injection molding
6. Features: Fire retardant/flame retardant
7. Contact material: Beryllium copper shrapnel
8. Insulator material: PEI, PPS
9. Number of cores: 20
10. Working temperature: -65～155 degrees Celsius
11. Lead spacing: 0.65mm
12. Service life: 20,000 times
13. Adaptation chip body width: 4.4mm
Features:
1. Using double contact technology, the contact is more stable
2. The seat shell is made of special engineering plastic, which has high strength and long life.
3. The shrapnel adopts imported beryllium copper material, which has low impedance and good elasticity
4. Thick gold plating layer, thick contact plating, ultra-low contact impedance, high reliability
Specification:
|
Package Weight
|
| One Package Weight |
0.02kgs / 0.05lb
|
| One Package Size |
15cm * 12cm * 6cm / 5.91inch * 4.72inch * 2.36inch
|
| Carton Weight |
5.00kgs / 11.02lb
|
| Carton Size |
52cm * 36cm * 37cm / 20.47inch * 14.17inch * 14.57inch
|
| Loading Container |
20GP: 385 cartons * 200 pcs = 77000 pcs
40HQ: 893 cartons * 200 pcs = 178600 pcs
|
|
