1. Compatible with PCI-E MINI card electromechanical specification revision 1.2
2. Compatible with Half/Full-size Mini card type from factor
3. Compliant with PCI-Express Base Specification Revision 1.1
4. Single Lane X1 PCI-express with throughput up to 2.5Gbps
5. Full-duplex operation at 10/100/1000Mbs
6. Half-duplex operation at 10/100Mbs
7. Fully Plug and Play compatible
8. 10/100/1000 data rate auto-negotiation operation
9. IPv4 and IPv6 checksum offload support
10. Fully Compliant with IEEE 802.3, 802.3 u, 802.3 ab
11. Support full duplex flow control (IEEE 802.3 x)
12. Supports IEEE802.1P Layer 2 Priority Encoding
13. Supports IEEE802.1Q VLAN tagging
14. Receive Side Scaling(RSS) with two hardware receive queues
15. Supports jumbo frame to 9k bytes
16. Cross-over detection and Auto-correction operation
Specification:
|
Package Weight
|
| One Package Weight |
0.10kgs / 0.23lb
|
| One Package Size |
17.5cm * 12.5cm * 3cm / 6.89inch * 4.92inch * 1.18inch
|
| Carton Weight |
30.00kgs / 66.14lb
|
| Carton Size |
90cm * 82cm * 25cm / 35.43inch * 32.28inch * 9.84inch
|
| Loading Container |
20GP: 144 cartons * 288 pcs = 41472 pcs
40HQ: 335 cartons * 288 pcs = 96480 pcs
|
|
